Randomized Hough transform
Hough transforms are techniques for object detection, a critical step in many implementations of computer vision, or data mining from images. Specifically, the Randomized Hough transform is a probabilistic variant to the classical Hough transform, and is commonly used to detect curves (straight line, circle, ellipse, etc.) The basic idea of Hough transform (HT) is to implement a voting procedure for all potential curves in the image, and at the termination of the algorithm, curves that do exist in the image will have relatively high voting scores. Randomized Hough transform (RHT) is different from HT in that it tries to avoid conducting the computationally expensive voting process for every nonzero pixel in the image by taking advantage of the geometric properties of analytical curves, and thus improve the time efficiency and reduce the storage requirement of the original algorithm. == Motivation == Although Hough transform (HT) has been widely used in curve detection, it has two major drawbacks: First, for each nonzero pixel in the image, the parameters for the existing curve and redundant ones are both accumulated during the voting procedure. Second, the accumulator array (or Hough space) is predefined in a heuristic way. The more accuracy needed, the higher parameter resolution should be defined. These two needs usually result in a large storage requirement and low speed for real applications. Therefore, RHT was brought up to tackle this problem. == Implementation == In comparison with HT, RHT takes advantage of the fact that some analytical curves can be fully determined by a certain number of points on the curve. For example, a straight line can be determined by two points, and an ellipse (or a circle) can be determined by three points. The case of ellipse detection can be used to illustrate the basic idea of RHT. The whole process generally consists of three steps: Fit ellipses with randomly selected points. Update the accumulator array and corresponding scores. Output the ellipses with scores higher than some predefined threshold. === Ellipse fitting === One general equation for defining ellipses is: a ( x − p ) 2 + 2 b ( x − p ) ( y − q ) + c ( y − q ) 2 = 1 {\displaystyle a(x-p)^{2}+2b(x-p)(y-q)+c(y-q)^{2}=1} with restriction: a c − b 2 > 0 {\displaystyle ac-b^{2}>0} However, an ellipse can be fully determined if one knows three points on it and the tangents in these points. RHT starts by randomly selecting three points on the ellipse. Let them be X 1 {\displaystyle X_{1}} , X 2 {\displaystyle X_{2}} and X 3 {\displaystyle X_{3}} . The first step is to find the tangents of these three points. They can be found by fitting a straight line using least squares technique for a small window of neighboring pixels. The next step is to find the intersection points of the tangent lines. This can be easily done by solving the line equations found in the previous step. Then let the intersection points be T 12 {\displaystyle T_{12}} and T 23 {\displaystyle T_{23}} , the midpoints of line segments X 1 X 2 {\displaystyle X_{1}X_{2}} and X 2 X 3 {\displaystyle X_{2}X_{3}} be M 12 {\displaystyle M_{12}} and M 23 {\displaystyle M_{23}} . Then the center of the ellipse will lie in the intersection of T 12 M 12 {\displaystyle T_{12}M_{12}} and T 23 M 23 {\displaystyle T_{23}M_{23}} . Again, the coordinates of the intersected point can be determined by solving line equations and the detailed process is skipped here for conciseness. Let the coordinates of ellipse center found in previous step be ( x 0 , y 0 ) {\displaystyle (x_{0},y_{0})} . Then the center can be translated to the origin with x ′ = x − x 0 {\displaystyle x'=x-x_{0}} and y ′ = y − y 0 {\displaystyle y'=y-y_{0}} so that the ellipse equation can be simplified to: a x ′ 2 + 2 b x ′ y ′ + c y ′ 2 = 1 {\displaystyle ax'^{2}+2bx'y'+cy'^{2}=1} Now we can solve for the rest of ellipse parameters: a {\displaystyle a} , b {\displaystyle b} and c {\displaystyle c} by substituting the coordinates of X 1 {\displaystyle X_{1}} , X 2 {\displaystyle X_{2}} and X 3 {\displaystyle X_{3}} into the equation above. === Accumulating === With the ellipse parameters determined from previous stage, the accumulator array can be updated correspondingly. Different from classical Hough transform, RHT does not keep "grid of buckets" as the accumulator array. Rather, it first calculates the similarities between the newly detected ellipse and the ones already stored in accumulator array. Different metrics can be used to calculate the similarity. As long as the similarity exceeds some predefined threshold, replace the one in the accumulator with the average of both ellipses and add 1 to its score. Otherwise, initialize this ellipse to an empty position in the accumulator and assign a score of 1. === Termination === Once the score of one candidate ellipse exceeds the threshold, it is determined as existing in the image (in other words, this ellipse is detected), and should be removed from the image and accumulator array so that the algorithm can detect other potential ellipses faster. The algorithm terminates when the number of iterations reaches a maximum limit or all the ellipses have been detected. Pseudo code for RHT: while (we find ellipses AND not reached the maximum epoch) { for (a fixed number of iterations) { Find a potential ellipse. if (the ellipse is similar to an ellipse in the accumulator) then Replace the one in the accumulator with the average of two ellipses and add 1 to the score; else Insert the ellipse into an empty position in the accumulator with a score of 1; } Select the ellipse with the best score and save it in a best ellipse table; Eliminate the pixels of the best ellipse from the image; Empty the accumulator; }
Scene statistics
Scene statistics is a discipline within the field of perception. It is concerned with the statistical regularities related to scenes. It is based on the premise that a perceptual system is designed to interpret scenes. Biological perceptual systems have evolved in response to physical properties of natural environments. Therefore natural scenes receive a great deal of attention. Natural scene statistics are useful for defining the behavior of an ideal observer in a natural task, typically by incorporating signal detection theory, information theory or estimation theory. == Within-domain versus across-domain == Geisler (2008) distinguishes between four kinds of domains: (1) Physical environments (2) Images/Scenes (3) Neural responses and (4) Behavior. Within the domain of images/scenes one can study the characteristics of information related to redundancy and efficient coding. Across-domain statistics determine how an autonomous system should make inferences about its environment, process information and control its behavior. To study these statistics it is necessary to sample or register information in multiple domains simultaneously. == Applications == === Prediction of picture and video quality === One of the most successful applications of Natural Scenes Statistics Models has been perceptual picture and video quality prediction. For example, the Visual Information Fidelity (VIF) algorithm, which is used to measure the degree of distortion of pictures and videos, is used extensively by the image and video processing communities to assess perceptual quality. This is often after processing, such as compression, which can degrade the appearance of a visual signal. The premise is that the scene statistics are changed by distortion and that the visual system is sensitive to the changes in the scene statistics. VIF is heavily used in the streaming television industry. Other popular picture quality models that use natural scene statistics include BRISQUE and NIQE, both of which are no-reference since they do not require any reference picture to measure quality against.
Luma (video)
In video, luma ( Y ′ {\displaystyle Y'} ) represents the brightness in an image (the "black-and-white" or achromatic portion of the image). Luma is typically paired with chroma. Luma represents the achromatic image, while the chroma components represent the color information. Converting R′G′B′ sources (such as the output of a three-CCD camera) into luma and chroma allows for chroma subsampling: because human vision has finer spatial sensitivity to luminance ("black and white") differences than chromatic differences, video systems can store and transmit chromatic information at lower resolution, optimizing perceived detail at a particular bandwidth. == Luma versus relative luminance == Luma is the weighted sum of gamma-compressed R′G′B′ components of a color video—the prime symbols ′ denote gamma compression. The word was proposed to prevent confusion between luma as implemented in video engineering and relative luminance as used in color science (i.e. as defined by CIE). Relative luminance is formed as a weighted sum of linear RGB components, not gamma-compressed ones. Even so, luma is sometimes erroneously called luminance. SMPTE EG 28 recommends the symbol Y ′ {\displaystyle Y'} to denote luma and the symbol Y {\displaystyle Y} to denote relative luminance. === Use of relative luminance === While luma is more often encountered, relative luminance is sometimes used in video engineering when referring to the brightness of a monitor. The formula used to calculate relative luminance uses coefficients based on the CIE color matching functions and the relevant standard chromaticities of red, green, and blue (e.g., the original NTSC primaries, SMPTE C, or Rec. 709). For the Rec. 709 (and sRGB) primaries, the linear combination, based on pure colorimetric considerations and the definition of relative luminance is: Y = 0.2126 R + 0.7152 G + 0.0722 B {\displaystyle Y=0.2126R+0.7152G+0.0722B} The formula used to calculate luma in the Rec. 709 spec arbitrarily also uses these same coefficients, but with gamma-compressed components: Y ′ = 0.2126 R ′ + 0.7152 G ′ + 0.0722 B ′ , {\displaystyle Y'=0.2126R'+0.7152G'+0.0722B',} where the prime symbol ′ denotes gamma compression. == Rec. 601 luma versus Rec. 709 luma coefficients == For digital formats following CCIR 601 (i.e. most digital standard definition formats), luma is calculated with this formula: Y 601 ′ = 0.299 R ′ + 0.587 G ′ + 0.114 B ′ {\displaystyle Y'_{\text{601}}=0.299R'+0.587G'+0.114B'} Formats following ITU-R Recommendation BT. 709 (i.e. most digital high definition formats) use a different formula: Y 709 ′ = 0.2126 R ′ + 0.7152 G ′ + 0.0722 B ′ {\displaystyle Y'_{\text{709}}=0.2126R'+0.7152G'+0.0722B'} Modern HDTV systems use the 709 coefficients, while transitional 1035i HDTV (MUSE) formats may use the SMPTE 240M coefficients: Y 240 ′ = 0.212 R ′ + 0.701 G ′ + 0.087 B ′ = Y 145 ′ {\displaystyle Y'_{\text{240}}=0.212R'+0.701G'+0.087B'=Y'_{\text{145}}} These coefficients correspond to the SMPTE RP 145 primaries (also known as "SMPTE C") in use at the time the standard was created. The change in the luma coefficients is to provide the "theoretically correct" coefficients that reflect the corresponding standard chromaticities ('colors') of the primaries red, green, and blue. However, there is some controversy regarding this decision. The difference in luma coefficients requires that component signals must be converted between Rec. 601 and Rec. 709 to provide accurate colors. In consumer equipment, the matrix required to perform this conversion may be omitted (to reduce cost), resulting in inaccurate color. == Luma and luminance errors == As well, the Rec. 709 luma coefficients may not necessarily provide better performance. Because of the difference between luma and relative luminance, luma does not exactly represent the luminance in an image. As a result, errors in chroma can affect luminance. Luma alone does not perfectly represent luminance; accurate luminance requires both accurate luma and chroma. Hence, errors in chroma "bleed" into the luminance of an image. Note the bleeding in lightness near the borders. Due to the widespread usage of chroma subsampling, errors in chroma typically occur when it is lowered in resolution/bandwidth. This lowered bandwidth, coupled with high frequency chroma components, can cause visible errors in luminance. An example of a high frequency chroma component would be the line between the green and magenta bars of the SMPTE color bars test pattern. Error in luminance can be seen as a dark band that occurs in this area.
Parasolid
Parasolid is a geometric modeling kernel originally developed by Shape Data Limited, now owned and developed by Siemens Digital Industries Software. It can be licensed by other companies for use in their 3D computer graphics software products. Parasolid's abilities include model creation and editing utilities such as Boolean modeling operators, feature modeling support, advanced surfacing, thickening and hollowing, blending and filleting, and sheet modeling. It also incorporates modeling with mesh surfaces and lattices. Parasolid also includes tools for direct model editing, including tapering, offsetting, geometry replacement and removing feature details with automated regeneration of surrounding data. Parasolid also provides wide-ranging graphical and rendering support, including hidden-line, wireframe and drafting, tessellation, and model data inquiries. To use Parasolid effectively, software developers need knowledge of CAD in general, computational geometry, and topology. Parasolid is available for Windows (32-bit, 64-bit and AArch64), Linux (64-bit and AArch64), macOS (Apple silicon and Intel), iOS, and Android. == Parasolid XT format == Parasolid parts are normally saved in XT format, which usually has the file extension .X_T. The format is documented and open. There is also a binary version of the format, usually with an .X_B extension, which is somewhat more compact. Both .X_T and .X_B are used for parts files. == Applications == It is used in many computer-aided design (CAD), computer-aided manufacturing (CAM), computer-aided engineering (CAE), product visualization, and CAD data exchange packages. Notable uses include:
The Drivers Cooperative
The Drivers Cooperative or Co-Op Ride is an American ridesharing company and mobile app that is a workers cooperative, owned collectively by the drivers. The cooperative launched in May 2021 in New York City, with the first 2,500 drivers issued their ownership certificates in a media event. The cooperative was co-founded by Grenadan immigrant and for hire vehicle driver Ken Lewis, labor organizer Erik Forman, and former Uber executive Alissa Orlando. Mohammad Hossen is the first member of the drivers' advisory board, which they plan to expand democratically as more drivers are onboarded. Other staff include software and industry veterans and in addition to co-founder Lewis, there are other drivers in management roles such as ex-driver and organizer David Alexis. The Co-Op Ride app is on the iOS and Android platforms and is built on Google Maps, Stripe, and Waze. By July, the app had been downloaded by 30,000 users and the number of drivers increased to 3,400, and by August there were 40,000 users. The cooperative is owned by the drivers themselves, and takes 15% from each ride for business overhead costs, as opposed to the 25% to 40% ride hail apps like Uber or Lyft take per ride. While being ultimately owned by the driver members, not by investors, the cooperative began with seed money from the Minnesota-based Community Development Financial Institution Shared Capital Cooperative, the local Lower East Side People's Federal Credit Union, and welcomed individual donations via crowdfunding in the form of revenue sharing debt on Wefunder. Each driver is a member of the cooperative and owns one share of the company and one vote in business and leadership decisions. In addition to a larger percentage of the fees per ride driven, each driver as a part-owner will also receive a share of the company's profits after loans and other expenses are paid, in the form of weighted dividends. The drivers use their own cars. The cooperative vets its owner-members further than what is already performed by the New York City Taxi and Limousine Commission (TLC), and gives a fixed price when a car is ordered and does not engage in surge pricing. The TLC imposed a minimum payrate for mobile app ridesharing companies operating in New York city in 2018. In 2021 that is $1.26 per mile which Uber and Lyft do not pay above; the cooperative pays a minimum mileage of $1.64. The cooperative intends to be able to set aside 10% of profits to community foundations and other non-profits and community organizations. The cooperative has engaged in advocacy around a policy agenda voted on by its members. Legislation to achieve this policy goal was introduced by State Senator Julia Salazar and Assemblymember Jessica González-Rojas, with the support of a coalition led by The Drivers Cooperative, United Auto Workers Region 9 and 9A, Sunrise Movement, New York Lawyers for the Public Interest, and New York Communities for Change.
Cinema 4D
Cinema 4D is a 3D software suite developed by the German company Maxon. == Overview == As of R21, only a single version of Cinema 4D is available. It replaces all previous variants, including BodyPaint 3D, and includes all features of the past 'Studio' variant. With R21, all binaries were unified. There is no technical difference between commercial, educational, or demo versions. The difference is now only in licensing. 2014 saw the release of Cinema 4D Lite, which came packaged with Adobe After Effects Creative Cloud 2014. "Lite" acts as an introductory version, with many features withheld. This is part of a partnership between the two companies, where a Maxon-produced plug-in, called Cineware, allows any variant to create a seamless workflow with After Effects. The "Lite" variant is dependent on After Effects CC, needing the latter application running to launch, and is only sold as a package component included with After Effects CC through Adobe. Initially, Cinema 4D was developed for Amiga computers in the early 1990s, and the first three versions of the program were available exclusively for that platform. With v4, however, Maxon began to develop the application for Windows and Macintosh computers as well, citing the wish to reach a wider audience and the growing instability of the Amiga market following Commodore's bankruptcy. It was also released for BeOS. On Linux, Cinema 4D is available as a commandline rendering version. == Modules and older variants == From R12 to R20, Cinema 4D was available in four variants. A core Cinema 4D 'Prime' application, a 'Broadcast' version with additional motion-graphics features, 'Visualize,' which adds functions for architectural design and 'Studio,' which includes all modules. From Release 8 until Release 11.5, Cinema 4D had a modular approach to the application, with the ability to expand upon the core application with various modules. This ended with Release 12, though the functionality of these modules remains in the different flavors of Cinema 4D (Prime, Broadcast, Visualize, Studio) The old modules were: Advanced Render (global illumination/HDRI, caustics, ambient occlusion and sky simulation) BodyPaint 3D (direct painting on UVW meshes; now included in the core. In essence Cinema 4D Core/Prime and the BodyPaint 3D products are identical. The only difference between the two is the splash screen that is shown at startup and the default user interface.) Dynamics (for simulating soft body and rigid body dynamics) Hair (simulates hair, fur, grass, etc.) MOCCA (character animation and cloth simulation) MoGraph (Motion Graphics procedural modelling and animation toolset) NET Render (to render animations over a TCP/IP network in render farms) PyroCluster (simulation of smoke and fire effects) Prime (the core application) Broadcast (adds MoGraph2) Visualize (adds Virtual Walkthrough, Advanced Render, Sky, Sketch and Toon, data exchange, camera matching) Studio (the complete package) == Version history == == Use in industry == A number of films and related works have been modeled and rendered in Cinema 4D, including: == Cinebench == Cinebench is a cross-platform test suite which tests a computer's hardware capabilities. It can be used as a test for Cinema 4D's 3D modeling, animation, motion graphic and rendering performance on multiple CPU cores. The program "target[s] a certain niche and [is] better suited for high-end desktop and workstation platforms". Cinebench is commonly used to demonstrate hardware capabilities at tech shows to show a CPU performance, especially by tech YouTubers and review sites.
